Power supply
- version with electronic ballast:
- 200 -240V 50/60Hz - 100-120V 50/60Hz - version with electromagnetic ballast:
- 220 -240V 50Hz - 200 -220V 60Hz
Lamp
Metal iodide lamp powered by a special unit incorpo-rated in the fixture.
- type HMI 575W/SEL
- Cap G22 - Color temperature 6.000 K
-Luminous flux 49.000 lm - Average life 1.000 h
Power consumption
- version with electronic ballast:
1200VA at 230V 50Hz - version with electromagnetic ballast:
900VA at230V 50Hz (70μF standard power factor correction)
Motors
- N° 11 stepped motors with microstepping operationand full microprocessor control.
Channels
- N° 11 + 3 control channels.
Weight
- Electronic ballast version: 40.1 kg (88 lbs).
- Electromagnetic ballast version: 48 kg (105 lbs 10 oz).
